4 Inch Hose Floats High Floating Design Low Water Absorption Saltwater Compatible
Introduction
Hongruntong Marine’s Heavy-Duty Hose Floats are engineered for demanding offshore and marine environments. Made from UV-resistant, high-buoyancy polyethylene, these floats ensure optimal hose positioning while preventing tangling and abrasion. Their corrosion-proof, saltwater-compatible design guarantees long-term durability, even in harsh conditions. With quick-release buckles and adjustable straps, installation is effortless, reducing downtime. Ideal for firefighting, dredging, and oil transfer operations, our floats enhance safety and efficiency on any vessel or platform.
Specifications
| Item | Requirements | Item | Requirements |
| Tensile Strength | ≥13.1MPa | Water Absorption | 1-2g/100cm2 |
| Break Elongation | ≥11.1% | Breaking Strength | 0.08-0.1MPa |
| Impact Strength | ≥32.4KJ/m2 | Breaking Elongation | 4-6% |
| Bending Strength | ≥15.7MPa | Compressive Strength | 0.1-0.24MPa |
| Weather Resistance After total aging energy≥3.5GJ/m2 | Break Elongation %≥ | 10 |
| Oxidative Induction Time 200°Cmm≥ | 10 |
| Characteristic |
| * Good flexibility, excellent impact resistance, particularly suitable for construction in open sea | * Lightweight weight easy to install and handle, low costs for moving | * High corrosive resistance, 3 times longer life than steel floats | * Higher cost performance than steel float |
| I.D. | O.D. | Length | Thickness | Net Buoyancy |
| mm | mm | mm | mm | KGS/Float |
| 160-180 | 500 | 800 | 4 | 280 |
| 225 | 600 | 700 | 4 | 320 |
| 280 | 700 | 900 | 4 | 450 |
| 340 | 1000 | 1000 | 6 | 500 |
| 410 | 1100 | 1100 | 6 | 550 |
| 460 | 1200 | 1200 | 6 | 1200 |
| 510 | 1300 | 1300 | 7 | 1250 |
| 560 | 1300 | 1500 | 8 | 1360 |
| 610 | 1400 | 1600 | 8 | 1600 |
| 630 | 1480 | 1600 | 8 | 1950 |
| 680 | 1550 | 1800 | 8 | 2200 |
| 730 | 1620 | 1900 | 9 | 2300 |
| 780 | 1700 | 2000 | 9 | 2700 |
| 840 | 1850 | 2100 | 12 | 3200 |
| 890 | 2000 | 2400 | 12 | 4600 |
| 940 | 2040 | 2500 | 13 | 4900 |
| 1150 | 2400 | 2600 | 14 | 6500 |
| *NOTE: The floaters customized are available. |
Key Features
Marine Grade UV Stabilization
Our floats incorporate advanced UV inhibitors that provide 2,000+ hours of accelerated weathering resistance (ASTM G154 tested), ensuring no degradation or color fading in prolonged sunlight exposure - critical for offshore operations.
High Density Buoyancy Core
Engineered with closed-cell polyethylene foam (4.5lb/ft³ density) that delivers 22% greater buoyancy per unit volume compared to standard EVA foam, while maintaining exceptional compression resistance.
Saltwater Corrosion Protection
Feature triple-layer protection: (1) anti-corrosive polymer shell, (2) zinc-plated stainless steel hardware, and (3) sacrificial anode ports - achieving 500-hour salt spray test compliance (ASTM B117).
Industrial Grade Impact Resistance
Rib-reinforced structure withstands 50J direct impacts (ASTM D256) without cracking - 3X more durable than conventional float designs for heavy construction or mining applications.
Applications
► Offshore oil rig hose support
► Ship-to-shore fuel transfer
► Dredging operations
► Floating pipeline systems
► Marine salvage operations
Advantages
Smart Technology Integration
We offer optional RFID/NFC-enabled floats for modern asset tracking and management.
Large Scale Production Capacity
Our facilities can handle both small custom orders and high-volume production runs efficiently.
Global Distribution Network
We have established logistics partnerships to ensure reliable worldwide delivery.
Comprehensive Customer Support
We provide lifetime technical assistance and strong warranty coverage for all products.
FAQ
1. What buoyancy capacity do your hose floats provide?
Our standard models offer 50–500 kg buoyancy per unit, with custom solutions available for higher load requirements.
2. Are your hose floats UV-resistant?
Yes, they feature UV-stabilized polymers tested for 2,000+ hours under ASTM G154, ensuring long-term sun exposure resistance.
3. What hose diameters are compatible?
We support ½" to 3" diameters as standard, with larger sizes (up to 6") available for industrial applications.
4. Do you offer corrosion-resistant options?
All models include 316 stainless steel hardware and saltwater-proof coatings, passing 500-hour salt spray tests (ASTM B117).
